# JCasC configurations.yaml 예시

jenkins:
  systemMessage: |
    <h2>Jenkins 자동화 구성 (JCasC)</h2>
    <ul>
      <li>문의: devops@example.com</li>
      <li>매주 일요일 23:45 점검</li>
    </ul>
  numExecutors: 4
  remotingSecurity:
    enabled: true
    slaveAgentPort: 0
  globalNodeProperties:
    - envVars:
        env:
          - key: JAVA_HOME
            value: /usr/lib/jvm/java-17-openjdk
          - key: TZ
            value: Asia/Seoul
  securityRealm:
    local:
      allowsSignup: false
      users:
        - id: "admin"
          password: "${JENKINS_ADMIN_PASSWORD}"
        - id: "devuser"
          password: "${JENKINS_DEV_PASSWORD}"
  authorizationStrategy:
    loggedInUsersCanDoAnything:
      allowAnonymousRead: false
  crumbIssuer:
    standard:
      excludeClientIPFromCrumb: false
  unclassified:
    location:
      url: http://localhost:8080
  views:
    - all:
        name: "전체 빌드"
    - list:
        name: "주요 파이프라인"
        jobNames:
          - "example-pipeline"
  updateCenter:
    sites:
      - id: "default"
        url: "https://updates.jenkins.io/update-center.json"
​
12345678910111213141516171819202122232425262728293031323334353637383940414243444546474849

​# JCasC pipeline.yaml 예시

jobs:
  - script: >
      pipelineJob('example-pipeline') {
        definition {
          cps {
            script("""
              pipeline {
                agent any
                stages {
                  stage('Build') {
                    steps {
                      echo 'Building...'
                    }
                  }
                  stage('Test') {
                    steps {
                      echo 'Testing...'
                    }
                  }
                  stage('Deploy') {
                    steps {
                      echo 'Deploying...'
                    }
                  }
                }
              }
            """)
            sandbox(true)
          }
        }
      }
123456789101112131415161718192021222324252627282930313233

# JCasC plugins.txt 예시
configuration-as-code:latest
git:latest
workflow-aggregator:latest
matrix-auth:latest
credentials:latest
...
1
2
3
4
5
6
7

# JCasC Dockerfile 예시

FROM jenkins/jenkins:lts

# 플러그인 설치
COPY plugins.txt /usr/share/jenkins/ref/plugins.txt
RUN /usr/local/bin/install-plugins.sh < /usr/share/jenkins/ref/plugins.txt

# JCasC 및 파이프라인 Job 설정 복사
COPY configuration.yaml /var/jenkins_home/casc_configs/configuration.yaml
COPY pipeline.yaml /var/jenkins_home/casc_configs/pipeline.yaml

# JCasC 환경변수 지정
ENV CASC_JENKINS_CONFIG="/var/jenkins_home/casc_configs"

# Setup Wizard 비활성화
ENV JAVA_OPTS -Djenkins.install.runSetupWizard=false

# Jenkins 기동 시 pipeline.yaml의 Job 정의를 반영하는 스크립트 추가
COPY init-jobs.groovy /usr/share/jenkins/ref/init.groovy.d/init-jobs.groovy​
1234567891011121314151617181920
